Infinova
Price Available on Request
V6812IR-H02 series HD 2MP IR IP minidome camera features 1/2.8" progressive scan CMOS sensor and built-in 3.0 megapixel fixed lens (4mm/6mm/8mm/12mm optional). With H.264/M-JPEG compression format utilized, this camera can output HD full-frame videos with the resolution up to 1080P. The built-in dot matrix IR illuminators allow a maximum of 20 meters night vision distance (the distance will be different for different lenses). The output power of the illuminator can be automatically adjusted according to the lighting condition, thus the IR illuminators will be free of full-load operation. This also lowers the overall power consumption and prolongs the lifespan of the device. The camera supports the function of strengthening ROI encoding, so as to improve the image quality of key areas under low-band network environment. The camera supports three simultaneous video streams. It also provides motion detection, privacy mask, video mask alarm, image snapshot, local recording, noise deduction, backlight compensation and WDR functions. Alarm can be associated with email sending and FTP upload. Compact structure makes it easy to install. Also, this camera provides 3-axis adjustment, easy to adjust the monitoring angle. V6812IR-H02 series is widely used in normal buildings, supermarkets, hotels, shops, parks, schools, factories, warehouses, underground parking lots and other high-resolution surveillance applications. 1/2.8" progressive scan CMOS sensor Built-in dot matrix IR illuminators, at 850nm wavelength, up to 20 meters night vision distance The illuminator output rate can be automatically adjusted according to the lighting condition IR-Cut Removable (ICR) Filter for Day/Night switching Three Simultaneous Video Streams: Dual H.264 & Scalable M-JPEG With resolution up to 1080P Smooth videos, with the frame rate up to 30fps Support one way audio input Support Horizontal/Vertical Mirror Support Corridor mode Support WDR function Backlight Compensation Local Recording Up to four ROI (Region of Interest) areas Up to four definable motion detection areas Up to four definable privacy mask areas Support video mask alarm Alarms triggered by motion detection link with email sending and FTP upload Support simultaneous access and parameter setting via Web Server from multiple clients Compatible or able to integrate with Infinova V2216 and other digital video surveillance software Standard SDK is provided for easy integration with other systems Onvif Profile S Compact structure for surface mount, 3-axis adjustment Support analog video output 12VDC power supply IP55 environmental rating V6812IR-H0265SA HD Megapixel IR IP minidome camera, Day/night, 1/2.8 inch CMOS sensor, H.264/M-JPEG, indoor, 2.0Mpx, 12VDC, Surface mount, 4mm fixed lens V6812IR-H0265SB HD Megapixel IR IP minidome camera, Day/night, 1/2.8 inch CMOS sensor, H.264/M-JPEG, indoor, 2.0Mpx, 12VDC, Surface mount, 6mm fixed lens V6812IR-H0265SC HD Megapixel IR IP minidome camera, Day/night, 1/2.8 inch CMOS sensor, H.264/M-JPEG, indoor, 2.0Mpx, 12VDC, Surface mount, 8mm fixed lens V6812IR-H0265SD HD Megapixel IR IP minidome camera, Day/night, 1/2.8 inch CMOS sensor, H.264/M-JPEG, indoor, 2.0Mpx, 12VDC, Surface mount, 12mm fixed lens N3925-12D-1 Exterior power, 100~240VAC input, 12VDC output, 1.5A
296 Products
